10PCS 5 Pin 3.5mm Pitch PCB Green Pluggable Terminal Block Connector with Separate Screw Hole (10Pcs 5P 3.5MM)
4.8 (24 items)
Limited Time SaleUS$3.83 cheaper than the new price!!
Free cash-on-delivery fees for purchases over $99
Product details
| Management number | 211028053 | Release Date | 2026/04/04 | List Price | US$2.55 | Model Number | 211028053 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
MATERIAL Pilch 3.5mm Polos.2P-24P Screw: M2,Steel,Zinc plated Contach:Phosohor bronze Ni plated Wire cage:Brass,Ni Plaled Housing:PA66.UL94V-0 ELECTRICAL Rated voltage:300v Bated current: 8A Withstanding voltage:AC2000V 1Min Wire range:28-16AWG MECHANICAL Temperature range:-40°C-105°C MAX soldering:+ 250°C for 5 sec Torque: 0.2 Nm (1.8 lb.in) Strip length:7mm
- 3.5mm plug-in terminal block
- Pin Number:5
- Rated Value: 300V 8A
- Wire range: 28-16A WG
- Color: Green
| Gauge | 16.0 |
|---|---|
| Model | Celent_CL107-111 |
| Pitch | 3.5 Millimeters |
| Voltage | 300 Volts |
| Brand Name | Cermant |
| Part Number | Celent_CL107-111 |
| Manufacturer | Cermant |
| Material Type | Brass |
| Mounting Type | plug-in |
| Connector Type | Screw |
| Current Rating | 8 Amps |
| Number Of Poles | 5 |
| Centerline Length | 7 Millimeters |
| Specification Met | UL |
| Number Of Contacts | 5 |
| Number of Positions | 5 |
| Upper Temperature Rating | 105 Degrees Celsius |
