4 Row Aluminum Radiator For 1999-2005 Ford F250 F350 F450 F550 Super Duty 6.8L/7.3L V8 Powerstroke Radiador 2000 2001 2002 99 01 02 03 04 05 Radiators Shroud 2x12" Fans Thermostat Relay Kit

FitmentFor 2000-2005 Ford Excursion Limited XLT XLS Eddie 6.8L 7.3L V8 V10 EngineFor 1999-2004 Ford F-250 F-350 F-450 F-550 Super Duty 6.8L 7.3L V8 V10 EngineFor 1999-2004 Ford F-450 XL/F-53 Base 6.8L 7.3L V8 V10 EnginePackage Include:1 X 4-Row AA5052 Aluminum Radiator1 X CNC Machined Radiator Cap1 X AA5052 Aluminum Shroud2 X 12" Fans (Includes mounting kits)1 X Thermostat Relay KitRadiator DetailsRow Count: 4 RowCore Size: 26.46"H x 29.45"W x 2.44"TOverall Size: 31.69"L x30.31"W x6.30"HInlet/Outlet: 1.77"/1.77"Transmission oilcooler: YesPerformance: Up to 30%~45% More CoolingRadiator Crafts:100% welded by TIG, No EpoxyPlacement on Vehicle: Engine CompartmentMounting Style: Bolt-OnFitment Type: Direct ReplacementSurface Finish: Aircraft Grade Raw Aluminum Tank & CorePetcoke Drain: OEM Style Brass Petcoke DrainRadiator Cap: CNC Machined Filler Neck And CapFans SizeMaximum Fan CFM: 2300±200Fan Diameter X Height X Thickness:12.05" X 12.05" X 2.5"Number of Blades: 10 blades (Plastic) Amp Draw: 12.70 ampsMaximum Fan RPM: 2,250 rpmRelay Kit Instructions:RED + connect directly to battery.WHITE wire to ignition switch power source.BLACK goes to thermos switch.BLUE wire goes to the Fans.Thermostat Relay Kit:Universal fit for any automotive vehicle and electric fan.Activates by grounding electric fans at preset temperature.180'F turn-on temperature, 165'F turn-off temperature.3/8" NPT thread-in brass probe w/ 1/2" NPT adapter included.Probe typically threads into radiator, water outlet or manifold.Part NumberManufacturer Part Number:CU2171,2171,FO3010157,FO3010240,RAD2171, SBR2171

• 4 Row Core AA5052 Aluminum Radiator for 2000-2005 Ford Excursion Limited XLT XLS Eddie, for 1999-2004 Ford F-250 F-350 F-450 F-550 Super Duty/F-450 XL/F-53 Base 6.8L 7.3L V8 V10 Engine Radiators 2001 2002 2003 2005 99 01 02 03 04 05
• Core Size: 26.46"H x 29.45"W x 2.44"T; Overall Size: 31.69"L x30.31"W x6.30"H; Inlet/Outlet: 1.77"/1.77"; Transmission oilcooler: Yes
• High Performance. Full AA5052 Aircraft Aluminum craftsmanship radiator & exclusive tube design that dramatically increases cooling efficiency by up to 30%~45%, strong and durable, 100% welded by TIG, No Epoxy. 100% Leak Tested
• Easy to Install. Meticulously built to superior OE standards for a precise fit, direct bolt-on replacement. No Drilling or Modifications Needed for Installation
• Crafted by our professional team using the highest-grade materials for exceptional longevity.
