Digital Manifold Gauge Pressure Gauge Refrigeration Vacuum Pressure Manifold Tester HVAC Temperature Tester Valve Tool Kit

Features:--It can measure double pressure (gauge pressure) at the same time, as well as dual temperature measurement, with automatic multi-unit pressure conversion, automatic conversion of temperature Celsius / Fahrenheit, to facilitate different needs.--Built-in 89 kinds of refrigerant pressure-evaporation temperature database, also calculate the subcooling superheat, to facilitate direct reading of operating process data.--It tests percentage of vacuum measurement; pressure leak measurement, leak time speed record.EC/EN61010-1 safety standards for design and production.1)Pressure testing ranges from -101Kpa to 6Mpa2) The limit pressure is 10 Mpa3) The maximum operating pressure of standard hose is 600 PSI ( approximate 4.13 Mpa). The limit pressure is 3000 PSI (approximate 20.68 Mpa).4) Please confirm the rated pressure value of the tested equipment before testing. Do not use it if it exceeds the range of the instrument.Specifications:Pressure test: gauge pressurePressure test unit: Kpa; Mpa; bar; inHg; PSIPressure test range: 0 Kpa – 6000 KpaPressure test resolution: 1 KpaPressure test accuracy: +/- 0.5 %(FS)+ 5dgtPressure overload limit: 10000 KpaVacuum test: relative vacuumVacuum test unit: Kpa; Mpa; bar; inHg; PSIVacuum test range: -101 Kpa – 0 KpaVacuum test resolution: 1 KpaTemperature test unit: °C, °FTemperature test range: -40°C–150°C (-40°F–302°F)Temperature test resolution:0.1°C (-40°C–99.9°C), 1°C (100°C–150°C)0.1°F (-40°F–99.9°F), 1°F (100°F–302°F)Temperature test accuracy: +/- 0.5 °C + 2dgt +/- 0.9 °F + 2dgtBuilt-in 89 kinds of refrigerant NIST: According to American NIST standardPower Supply: 4 X 1.5V(AA) Battery not includeDimensions: 170*110*50mm weight: 950gD517A Pacakge list:1* Refrigerantion Digital Manifold Gauge1* User Manual2*Temperature Clip3*Test Pipe1* Suitcase

• 1, The intelligent electronic refrigerant group instrument is an auxiliary instrument for the installation, testing and maintenance of refrigeration equipment such as air conditioners and cold storage.
• 2, The instrument has double pressure test, dual temperature test (need test clip,not include), digital readout, multi-unit switching, multi-mode function and built-in refrigerant database.
• 3, The instrument uses high-strength engineering plastics and flexible non-slip silicone design, the whole machine is solid and comfortable to hold.
• 4, Built-in 32-bit digital processing unit and high-precision data acquisition unit, high data and stability.
• 5, Built-in 32-bit digital processing unit and high-precision data acquisition unit, high data and stability. Large-size liquid crystal display, LCD backlight support, data display clear and easy to read, convenient light operation.
